| Thermal Imaging Parameters |
|---|
| Detector | Uncooled VOx detector |
|---|
| Infrared Resolution | 384×288 |
|---|
| Pixel pitch | 17μm |
|---|
| Spectral Band | 8μm~14μm |
|---|
| Thermal Sensitivity (NETD) | <50mK |
|---|
|
| Temperature Measurement Function |
|---|
| Measurement Range | -20℃~+150℃,0℃~550℃ |
|---|
| Measurement Accuracy | ±2°C or ±2% of readings, whichever is greater. |
|---|
| Temperature Measurement Correction | Reflected temperature, ambient temperature, atmospheric transmissivity, object emissivity, distance |
|---|
| Measurement Tool | Settings of measurement rules for a total of 12 points, lines, and areas Supports isotherm setting |
|---|
| Temperature Width Stretch | Support temperature width stretch |
|---|
|
| Image and Video |
|---|
| Frame Rate | 50Hz |
|---|
| Palettes | 18 color palettes including black-hot, white-hot, iron red, rainbow, etc. |
|---|
| Video Standards | H.264, H.265 |
|---|
| Thermal Image Capture | Support thermal image capture and secondary analysis |
|---|
| Mirror Image | Horizontal/Vertical/Diagonal |
|---|
| Digital Zoom | 1.0~8.0 continuous zoom (step size: 0.1) |
|---|
|
| System Interface |
|---|
| Communication interface | RJ45，supporting Gigabit network and customized RS485 for Pecol-D protocol. |
|---|
| Alarm Interface | 1-channel alarm output (optional) |
|---|
| Video Interface | 1-channel analog video |
|---|
| Network Protocol | TCP, UDP, ICMP, DHCP, RTSP |
|---|
| Interface Protocol | ONVIF, GB28181 |
|---|
|
| Device Specifications |
|---|
| Operating Temperature | -20℃~+60℃ |
|---|
| Power supply mode | 10~36V DC, POE |
|---|
| Typical Power Consumption | ≤3W |
|---|
| Dimensions | 56mm×51mm×119mm |
|---|
| Weight | About 430g |
|---|
|
