| Thermal Imaging |
|---|
| Detector Type | Uncooled infrared detector |
|---|
| Infrared Resolution | 256×192 |
|---|
| Al Real-time Super-resolution | 320×240 |
|---|
| Pixel Size | 12μm |
|---|
| Spectral Band | 7.5-14μm |
|---|
| NETD | ＜40mK (25°C,F1.0) |
|---|
| Frame Rate | 25 Hz |
|---|
| Lens Focal Length | 3.2mm |
|---|
| FOV | 56°×42° |
|---|
| IFOV | 3.8mrad |
|---|
| Focusing Mode | Fixed focus |
|---|
| Minimum Imaging Distance | 0.3m |
|---|
| Measurement Range | -20°C~+150°C, 100°C~550°C |
|---|
| Measurement Accuracy | ±2°C or ±2% of readings, whichever is greater |
|---|
|
| Imaging Display |
|---|
| Display | 2.8 inch, 320×240 |
|---|
| Visible Light Camera | 2 megapixels |
|---|
| Digital Zoom | 1×, 2×, 4× |
|---|
| Palettes | 7 options |
|---|
| Image Mode | Infrared, visible light, PIP, dual-spectrum fusion |
|---|
| Temperature Width Stretch | Auto |
|---|
|
| Image Storage |
|---|
| Storage Medium | Standard 32GB MicroSD, up to 128G |
|---|
|
| Measurement and Analysis |
|---|
| Analysis Functions on the Device | Central temperature point/Highest temperature point/Lowest temperature point/3 custom points |
|---|
| Supporting Software | PC (Infrared Analysis Software) & Mobile Device (iOS/Android APP) |
|---|
|
| System Functions |
|---|
| Communication Protocol | USB, WiFi |
|---|
| Alarm Type | Highest/Lowest temperature alarm in full frame; Image pop-ups, flash prompts; Auto image capture at alarm time (with temperature data). |
|---|
| Power Management | Auto shut-down setting |
|---|
|
| Others |
|---|
| Battery | Built-in rechargeable lithium-ion battery |
|---|
| Charging Mode | USB Type-C |
|---|
| Battery Life | About 15h |
|---|
| Interface | USB Type-C, SD card |
|---|
| Tripod Socket | UNC 1/4-20 interface for tripod |
|---|
| Operating Temperature | -10°C~+50°C |
|---|
| Operating Humidity | 10%~95% (non-condensing) |
|---|
| Storage Temperature | -20°C~+60°C |
|---|
| Ingress Protection Rating | IP54 |
|---|
| Shock and Vibration | Shock: 25g (IEC 60068-2-27); vibration: 2.5g (IEC60068-2-6) |
|---|
| Weight and Dimensions | About 520g, 237×75×92mm |
|---|
| Authentication | CE/RoHS/CMA, etc. |
|---|
| Packing List | Infrared camera×1, USB cable, 32GB SD card, user manual, storage bag, certificate of qualification, calibration certificate |
|---|
|
