| Thermal Imaging |
|---|
| Infrared Resolution | 160×120 |
|---|
| Super Resolution | 320×240 |
|---|
| Spectral Band | 8-14μm |
|---|
| NETD | 40mK |
|---|
| Frame Rate | 25 Hz |
|---|
| Lens Focal Length | 2.6mm |
|---|
| FOV | 40°×30° |
|---|
| IFOV | 4.62 mrad |
|---|
| Focusing Mode | Fixed focus |
|---|
| Minimum Imaging Distance | 11cm |
|---|
| Measurement Range | -20~150℃; 100~550℃; auto switching |
|---|
|
| Imaging Display |
|---|
| Display | 2.8-inch; 240×320 resolution |
|---|
| Visible Light Camera | 2 megapixels |
|---|
| Palettes | 9 options |
|---|
| Image Mode | Infrared, visible light, PIP, fusion |
|---|
| Temperature Width Stretch | Automatic/Manual |
|---|
|
| Image Storage |
|---|
| Storage Medium | 8GB Internal Memory |
|---|
| Image File Format | JPEG |
|---|
|
| Video Recording and Transmission |
|---|
| Communication Interface | USB2.0 |
|---|
| Video Recording | Standard MP4 video recording |
|---|
| Video Resolution | 240×320 |
|---|
| Video Transmission | UVC (with temperature data) + Wi-Fi (without temperature data) |
|---|
|
| Measurement and Analysis |
|---|
| Measurement Accuracy | ±2°C or ±2% of readings (whichever is greater) |
|---|
| Measurement Unit | Celsius degree, Fahrenheit degree, Kelvin |
|---|
| Temperature Alarm | Supports (high and low temperature alarms) |
|---|
| Automatic lmage Capture Upon Alarm | Supports (with temperature data) |
|---|
| Color Alarm (lsotherm) | Above / Below / Between — The image within the isotherm range is displayed in pseudo color, while other areas are shown in white-hot mode |
|---|
| Analysis Functions on the Device | Central point / Highest temperature point / Lowest temperature point / 6 custom points |
|---|
| Analysis Report | PDFforma（trequiringsupportfromPCorAPPanalysissoftware） |
|---|
| Supporting Software | PC (Infrared Analysis Software) or Mobile (iOS/ Android APP) |
|---|
|
| System Functions |
|---|
| Connection Mode | USB2.0 Type-C |
|---|
| Laser Pointer | Support |
|---|
| Quick Start | support |
|---|
| WiFi | Support |
|---|
|
| Others |
|---|
| Battery | 2750mAh lithium-ion battery |
|---|
| Charging Time | Above 90% within 75 minutes |
|---|
| Charging Mode | USB2.0; Type-C cable charging; Not support fast charging |
|---|
| Battery Life | ≥10 hours |
|---|
| Tripod Socket | Support |
|---|
| Operating Temperature | -20°C~ 50°C |
|---|
| Storage Temperature | -40°C~ 70°C |
|---|
| Extemal Interface | Type-C USB2.0 Tripod socket |
|---|
| Ingress Protection Rating | IP54 |
|---|
| Shock and Vibration | shock: 25G (IEC60068-2-27); vibration: 2.5G (IEC60068-2-6); 2-meter drop |
|---|
| Weight and Dimensions | 265g±10g (including battery), 206.9×67×81.5mm |
|---|
| Packing List | Infrared thermal camera; user manual; USB cable; certificate of qualification; calibration certificate; wrist strap |
|---|
|
