| Thermal Module |
|---|
| Detector Type | VOx, uncooled FPA detectors |
|---|
| Spectral Range | 8~14μm |
|---|
| NETD | ≤40mK(@25°C, F#1.0, 25 Hz) |
|---|
| Resolution | 640×512 |
|---|
| Pixel Pitch | 12μm |
|---|
| Focal Length | 35mm/55mm |
|---|
|
| Smart Function |
|---|
| Fire Detection | Support |
|---|
| VCA | Support Line Crossing & Intrusion detection |
|---|
| 2-Way Audio | Support |
|---|
| Linkage Action | Video/ Snapshot/Email/Alarm output/sound and light alarm |
|---|
|
| System Interface |
|---|
| Power | DC 12V±25%/POE(802.3at) |
|---|
| Network | 1 RJ45 10M / 100M self-adaptive Ethernet port |
|---|
| Audio | 1 in/1 out |
|---|
| Storage | Micro SD memory（maximum 256G） |
|---|
| Serial Port | 1 channel RS485, can support Pelco protocol |
|---|
| Analog | 1 BNC |
|---|
| Reset | Support |
|---|
|
| General |
|---|
| Work Environment | -40℃~+70℃；<95%RH |
|---|
| Protection | IP66 |
|---|
| Certification | CE,ROHS,CE-EMC Test Report, FIPS 140-3 Level 3 |
|---|
| Power Consumption | ≤4W |
|---|
| Dimenstion(mm) | 334.7×121.5×104.4 |
|---|
| Weight | ≤1.5kg |
|---|
|
