| Image Function |
|---|
| Bi-Spectrum Image Fusion | Support |
|---|
|
| Thermal Module |
|---|
| Detector Type | VOx, uncooled FPA detectors |
|---|
| Spectral Range | 8~14μm |
|---|
| NETD | ≤40mK(@25°C, F#1.0, 25 Hz) |
|---|
| Resolution | 640×512 |
|---|
| Pixel Pitch | 12μm |
|---|
| Focal Length | 9.1mm/13mm/19mm/25mm/35mm |
|---|
|
| Optical Module |
|---|
| Sensor | 5MP 1/2.8" Progressive Scan CMOS |
|---|
| Resolution | 2560×1920 |
|---|
| Focal Length | 4mm/6mm/6mm/12mm/12mm |
|---|
| IR distance | 40m |
|---|
|
| Smart Function |
|---|
| Fire Detection | Support |
|---|
| VCA | Support Line Crossing & Intrusion detection |
|---|
| 2-Way Audio | Support |
|---|
| Linkage Action | Video/ Snapshot/Email/Alarm output/sound and light alarm |
|---|
|
| System Interface |
|---|
| Power | DC 12V±25%/POE(802.3at) |
|---|
| Network | 1 RJ45 10M / 100M self-adaptive Ethernet port |
|---|
| Audio | 1 in/1 out |
|---|
| Alarm | 2 in/1 out |
|---|
| Storage | Micro SD memory（maximum 256G） |
|---|
| Serial Port | 1 channel RS485, can support Pelco protocol |
|---|
| Reset | Support |
|---|
|
| General |
|---|
| Work Environment | -40℃~+70℃；<95%RH |
|---|
| Protection | IP66 |
|---|
| Certification | CE,ROHS,CE-EMC Test Report, FIPS 140-3 Level 3 |
|---|
| Power Consumption | ≤8W |
|---|
| Dimenstion(mm) | 319.5×121.5×103.6 |
|---|
| Weight | ≤1.8kg |
|---|
|
| More |
|---|
| Temperature Range | -20℃~+550℃ |
|---|
| Temperature Accuracy | ±2℃ or ±2% |
|---|
| Temperature Measurement | Support 4 temperature measure ment rules(fullframe, point, line, area) |
|---|
|
