| Thermal Imaging |
|---|
| Detector Type | Uncooled infrared detector |
|---|
| Infrared Resolution | 256×192 |
|---|
| Pixel Size | 12μm |
|---|
| Super Resolution | 512×384 |
|---|
| Spectral Band | 7.5-14μm |
|---|
| NETD | 40mK |
|---|
| Frame Rate | 25 Hz |
|---|
| Lens Focal Length | 7mm |
|---|
| FOV | 25°×19° |
|---|
| IFOV | 1.71mrad |
|---|
| Focusing Mode | Manual focusing |
|---|
| Minimum Imaging Distance | 0.1m |
|---|
| Measurement Range | -20°C ~ +550°C |
|---|
| Measurement Accuracy | ±2ºC or ±2% of readings, whichever is greater |
|---|
|
| Imaging Display |
|---|
| Visible Light Camera | 2 megapixels |
|---|
| Digital Zoom | 1×, 2×, 4× |
|---|
| Palettes | 10 |
|---|
| Image Mode | Infrared, visible light, PIP, dual-spectrum fusion |
|---|
| Temperature Width Stretch | Automatic/Manual |
|---|
|
| Image Storage |
|---|
| Storage Medium | lmages stored in the APP by default and downloadable to a local album |
|---|
|
| Measurement and Analysis |
|---|
| Analysis Functions on the Device | Up to 3 movable points, lines, and frames; up to 3 preset templates |
|---|
| Analysis Report | PDF format, supporting APP-side report generation |
|---|
| Supporting Software | PC (Infrared Analysis Software) & Mobile Device (iOS/Android APP) |
|---|
|
| Video Functions |
|---|
| Radiation Infrared Video Recording | Standard MP4 |
|---|
| Radiation Infrared Video Stream Transmission | TYPE-C/WLAN connection to PC, for real-time transmission of radiation infrared video streams |
|---|
| Video Resolution | 512×384 |
|---|
|
| System Functions |
|---|
| Communication Protocol | Wi-Fi, USB, Bluetooth |
|---|
| Voice Control | Voice assistant, quick command recognition |
|---|
|
| Others |
|---|
| Battery | Built-in 1050mAh lithium-ion battery |
|---|
| Charging Mode | USB Type-C direct charging |
|---|
| Battery Life | About 2h |
|---|
| External Interface | USB Type-C |
|---|
| Tripod Socket | UNC 1/4-20 interface for tripod |
|---|
| Operating Temperature | -10°C~+50°C |
|---|
| Operating Humidity | 10%~90% (non-condensing) |
|---|
| Storage Temperature | -20°C~+60°C |
|---|
| Ingress Protection Rating | IP54 |
|---|
| Shock and Vibration | Shock: 25g (IEC 60068-2-27); vibration: 2.5g (IEC60068-2-6) |
|---|
| Weight and Dimensions | About 142g,136.2x41x29.3mm |
|---|
| Certificates | CE/FCC/ROHS/SRRC/DGM/CMA |
|---|
| Package Contents | Thermal camera, Type-C cable, quickstart guide n certificate, certificate of conformity, portable bag |
|---|
|
