| Thermal Module |
|---|
| Detector Type | Uncooled VOx infrared detector |
|---|
| Spectral Range | 8~14μm |
|---|
| NETD | ≤40mK @25°C, F#1.0 |
|---|
| Resolution | 640×512 |
|---|
| Pixel Pitch | 12μm |
|---|
| Focal Length | 50mm/75mm/25~75mm/100mm Motorized lens |
|---|
|
| Optical Module |
|---|
| Sensor | 1/1.8-inch 4 megapixel CMOS |
|---|
| Resolution | 2688×1520 |
|---|
| Focal Length | 6~360mm 60X |
|---|
|
| PTZ |
|---|
| Pan | 360° continuous rotating |
|---|
| Tilt | -90°～+40° |
|---|
| Scan mode | Preset point/Patrol inspection group/Pattern/Area scanning/Linear scanning/Comprehensive patrol |
|---|
|
| Smart Function |
|---|
| Smoke & Fire Detection | Support |
|---|
| Fire Detection | Support |
|---|
| Radar Linkage | Support |
|---|
| Coaxial Linkage Amplification | Support |
|---|
| Intelligent Video Taking | Video taking triggered upon alarms or network failures (continue to transmit after recovery) |
|---|
| Intelligent Alarm | Support abnormality detection and linkage alarm for network anomaly, IP address conflict, memory error, illegal access, and burn alarm |
|---|
| Intelligent Detection | Support intelligent analysis of videos like tripwire and regional intrusion detection, and support passenger and vehicle recognition |
|---|
|
| System Interface |
|---|
| Communication | One RJ45 10M/100M adaptive Ethernet port, 1-channel RS485 |
|---|
| Audio | 1-channel audio input, 1-channel audio output |
|---|
| Alarm | 7-channel alarm input,2-channel alarm output |
|---|
| Storage | Support Micro SD card (up to 512G) |
|---|
|
| General |
|---|
| Work Environment | -40℃~+70℃；<90%RH |
|---|
| Power Input | DC 24V士15% |
|---|
| Protection | IP66; TVS 6000v, lightning protection, surge protection, and spike protection |
|---|
| Power Consumption | Max.75W |
|---|
| Dimenstion(mm) | 250x472x360mm (W x H x L) |
|---|
| Peripherals | Heater, wiper and fan |
|---|
| Weight | <20kg |
|---|
|
