| Image Function |
|---|
| Bi-Spectrum Image Fusion | Support |
|---|
|
| Thermal Module |
|---|
| Detector Type | VOx, uncooled FPA detectors |
|---|
| Spectral Range | 8~14μm |
|---|
| NETD | ≤40mK(@25°C, F#1.0, 25 Hz) |
|---|
| Resolution | 640×512 |
|---|
| Pixel Pitch | 12μm |
|---|
| Focal Length | 9.1mm/13mm/25mm/50mm Athermalized/Motorized lens |
|---|
|
| Optical Module |
|---|
| Sensor | 4MP 1/1.8" Progressive Scan CMOS |
|---|
| Resolution | 2560×1920 |
|---|
| Focal Length | 6.5~240mm, 37x |
|---|
| IR distance | 200m |
|---|
|
| PTZ |
|---|
| Pan | 360° continuous，0.1°~200°/s |
|---|
| Tilt | -27°~+90°，0.1°~120°/s |
|---|
| Preset | 1024 |
|---|
| Scan mode | Preset/Pattern Scan/Patrol Scan/ Linear Scan/Panorama Scan |
|---|
| Wiper | Auto-wiper |
|---|
|
| Smart Function |
|---|
| Fire Detection | Support |
|---|
| VCA | Support Line Crossing&Intrusion detection with AI human/Vehicle recognition |
|---|
| 2-Way Audio | Support |
|---|
| Linkage Action | Video/ Snapshot/Email/Alarm output |
|---|
|
| System Interface |
|---|
| Power | DC 24V±25% |
|---|
| Network | 1 RJ45 10M / 100M self-adaptive Ethernet port |
|---|
| Audio | 1 in/1 out |
|---|
| Alarm | 7 in/2 out |
|---|
| Storage | Micro SD memory（maximum 256G） |
|---|
| Serial Port | 1 channel RS485, can support Pelco protocol |
|---|
| Reset | Support |
|---|
|
| General |
|---|
| Work Environment | -40℃~+70℃；<95%RH |
|---|
| Protection | IP66 |
|---|
| Certification | CE,ROHS,CE-EMC Test Report, FIPS 140-3 Level 3 |
|---|
| Power Consumption | ≤8W |
|---|
| Dimenstion(mm) | Φ250×413 |
|---|
| Weight | ≤8kg |
|---|
|
| More |
|---|
| Temperature Range | -20℃~+550℃ |
|---|
| Temperature Accuracy | ±2℃ or ±2% |
|---|
| Temperature Measurement | Support 4 temperature measure ment rules(fullframe, point, line, area) |
|---|
|
