| Thermal Module |
|---|
| Detector Type | VOx, uncooled FPA detectors
|
|---|
| Spectral Range | 8~14μm
|
|---|
| NETD | ≤40mK(@25°C, F#1.0, 25 Hz)
|
|---|
| Resolution | 640×512
|
|---|
| Pixel Pitch | 12μm
|
|---|
| Focal Length | 9.1mm/13mm/25mm/50mm Athermalized/Motorized lens
|
|---|
|
| Optical Module |
|---|
| Sensor | 4MP 1/1.8" Progressive Scan CMOS
|
|---|
| Resolution | 2560×1920
|
|---|
| Focal Length | 6.5~240mm, 37x
|
|---|
| IR distance | 200m
|
|---|
|
| Image Function |
|---|
| Bi-Spectrum Image Fusion | Support
|
|---|
|
| PTZ |
|---|
| Pan | 360° continuous，0.1°~200°/s
|
|---|
| Tilt | -27°~+90°，0.1°~120°/s
|
|---|
| Preset | 1024
|
|---|
| Scan mode | Preset/Pattern Scan/Patrol Scan/ Linear Scan/Panorama Scan
|
|---|
| Wiper | Auto-wiper
|
|---|
|
| Smart Function |
|---|
| Fire Detection | Support
|
|---|
| VCA | Support Line Crossing&Intrusion detection with AI human/Vehicle recognition
|
|---|
| 2-Way Audio | Support
|
|---|
| Linkage Action | Video/ Snapshot/Email/Alarm output
|
|---|
|
| System Interface |
|---|
| Power | DC 24V±25%
|
|---|
| Network | 1 RJ45 10M / 100M self-adaptive Ethernet port
|
|---|
| Audio | 1 in/1 out
|
|---|
| Alarm | 7 in/2 out
|
|---|
| Storage | Micro SD memory（maximum 256G）
|
|---|
| Reset | Support
|
|---|
| Serial Port | 1 channel RS485, can support Pelco protocol
|
|---|
|
| General |
|---|
| Work Environment | -40℃~+70℃；<95%RH
|
|---|
| Protection | IP66
|
|---|
| Certification | CE,ROHS,CE-EMC Test Report, FIPS 140-3 Level 3
|
|---|
| Power Consumption | ≤8W
|
|---|
| Dimenstion(mm) | Φ250×413
|
|---|
| Weight | ≤8kg
|
|---|
|
| More |
|---|
| Temperature Range | -20℃~+550℃
|
|---|
| Temperature Accuracy | ±2℃ or ±2%
|
|---|
| Temperature Measurement | Support 4 temperature measure ment rules(fullframe, point, line, area)
|
|---|
|
