| Thermal Imaging |
|---|
| Detector Type | Uncooled infrared detector |
|---|
| Infrared Resolution | 256×192 |
|---|
| Pixel Size | 12μm |
|---|
| Spectral Band | 7.5-14μm |
|---|
| NETD | ＜40mK (25°C,F1.0) |
|---|
| Frame Rate | 25 Hz |
|---|
| Lens Focal Length | 7mm |
|---|
| FOV | 24.8°×18.7° |
|---|
| IFOV | 1.71mrad |
|---|
| Focusing Mode | Manual focusing |
|---|
| Minimum Imaging Distance | 0.2m |
|---|
| Measurement Range | -20°C~+150°C, 100°C~550°C |
|---|
| Measurement Accuracy | ±2°C or ±2% of readings, whichever is greater |
|---|
|
| Imaging Display |
|---|
| Display | 3.5-inch touch screen, 640×480 resolution |
|---|
| Visible Light Camera | 2 megapixels |
|---|
| Digital Zoom | 1× 2× 4× |
|---|
| Palettes | 10 |
|---|
| Image Mode | Infrared, visible light, PIP, dual-spectrum fusion |
|---|
| Temperature Width Stretch | Automatic/Manual |
|---|
|
| Image Storage |
|---|
| Storage Medium | Standard 32GB MicroSD, up to 128G |
|---|
| Text Notes | Support |
|---|
| Voice Annotation | Support |
|---|
| Image Naming | Auto/manual naming, naming by scanning QR code |
|---|
|
| Measurement and Analysis |
|---|
| Analysis Functions on the Device | Custom points/lines/areas; up to 10 points, 10 areas, and 10 lines; Center point/Hot and cold spot tracking and temperature display |
|---|
| Supporting Software | PC (Infrared Analysis Software) |
|---|
|
| System Functions |
|---|
| Communication Protocol | Wi-Fi, USB |
|---|
| Video Transmission | Support UVC video transmission |
|---|
| Laser Pointer | Support |
|---|
|
| Others |
|---|
| Battery | Rechargeable and detachable lithium-ion battery |
|---|
| Charging Mode | USB Type-C or desktop charger |
|---|
| Battery Life | About 8h (about 4h for a single battery) |
|---|
| Interface | USB Type-C, SD card |
|---|
| Tripod Socket | UNC 1/4-20 interface for tripod |
|---|
| Operating Temperature | -10°C~+50°C |
|---|
| Operating Humidity | 10%~95% (non-condensing) |
|---|
| Storage Temperature | -20°C~+60°C |
|---|
| Ingress Protection Rating | IP54 |
|---|
| Shock and Vibration | Shock: 25g (IEC 60068-2-27); vibration: 2.5g (IEC60068-2-6) |
|---|
| Weight and Dimensions | About 660g, 258.4×105.1×102.3mm |
|---|
| Authentication | CE/RoHS/CMA, etc. |
|---|
| Packing List | Thermal camera, 5V 2A power adaptor, USB cable, SD card, battery ×2, Quick Start Guide, battery charger, calibration certificate, package list, portable cloth bag |
|---|
|
| More |
|---|
| Cloud Services | Support cloud drive storage; support auto time sync |
|---|
|
