| Imaging Parameters |
|---|
| Detector Type | Uncooled VOx FPA |
|---|
| Spectral Range | 8‑14μm |
|---|
| NETD | ≤35mK(@25℃, F#1.0,25Hz) |
|---|
| Maximum Image Resolution | 1280×1024 |
|---|
| Pixel Pitch | 12μm |
|---|
| Focal Length | 55mm, 75mm |
|---|
| Image Resolution | 28672×1024, 39200×1024 |
|---|
| FOV | 360°×12.7°, 360°×9.4° |
|---|
| Scanning Speed | 2s/360°, 2.2s/360° |
|---|
| Sector Scanning Speed | 1.15s/180°, 1.43s/180°, 1.92s/180° |
|---|
| IFOV | 0.218mrad, 0.16mrad |
|---|
|
| Pan‑Tilt Parameters |
|---|
| Pan Range | 360° |
|---|
| Tilt Range | -20°~‑35° |
|---|
| Panoramic / Staring Mode | Supports |
|---|
|
| Network Functions |
|---|
| Platform Integration | ONVIF/SDK/API |
|---|
|
| Video Parameters |
|---|
| Image Format | JPEG |
|---|
| Video Compression Standard | H.264/H.265 |
|---|
|
| AI Functions |
|---|
| AI Recognition | AI Analytics with Human, Vehicle, Vessel, and Other Object Recognition |
|---|
| AI Detection | Supports Area Intrusion |
|---|
| Alarm Linkage | Recording / Snapshot / Email / PTZ Linkage |
|---|
| Fire Spot Detection | Supports |
|---|
|
| System Interfaces |
|---|
| Power Interface | DC 18‑36 V (30 V Typical) |
|---|
| Communication Interface | 1 × RJ45 10/100 Mbps Adaptive Ethernet Port |
|---|
| Storage Interface | Supports MicroSD Card (up to 1 TB) |
|---|
|
| General Specifications |
|---|
| Operating Temperature and Humidity | -40℃~+60℃; <90%RH |
|---|
| Ingress Protection Rating | IP66 |
|---|
| Power Consumption | Steady‑State Power Consumption <35 W; Peak ≤80 W |
|---|
| Dimensions | 382×260×386mm |
|---|
| Weight | 22kg |
|---|
|
| AI Detection Range |
|---|
| Lens Configuration | 55mm, 75mm |
|---|
| Person (1.8 × 0.5 m) | 1.1km, 1.6km |
|---|
| Vehicle (1.4 × 4.0 m) | 3.1km, 4.3km |
|---|
|
| AI Recognition Range |
|---|
| Lens Configuration | 55mm, 75mm |
|---|
| Person (1.8 × 0.5 m) | 0.6km, 0.8km |
|---|
| Vehicle (1.4 × 4.0 m) | 1.8km, 2.4km |
|---|
|
