| Imaging Parameters |
|---|
| Detector Type | Uncooled VOx FPA |
|---|
| Spectral Range | 8‑14μm |
|---|
| NETD | ≤35mK(@25℃, F#1.0,25Hz) |
|---|
| Maximum Image Resolution | 640×512 |
|---|
| Pixel Pitch | 12μm |
|---|
| Focal Length | 19mm, 25mm |
|---|
| Image Resolution | 9900×512, 13000×512 |
|---|
| FOV | 360°×18.4°, 360°×14° |
|---|
| Scanning Speed | 2.3s/360°, 2.85s/360° |
|---|
| Sector Scanning Speed | 1.15s/180°, 1.43s/180° |
|---|
|
| Pan‑Tilt Parameters |
|---|
| Pan Range | 360° |
|---|
| Tilt Range | +10°~‑10° |
|---|
| Scanning Mode | 360° Continuous Scanning / Sector Scanning |
|---|
|
| Network Functions |
|---|
| Platform Integration | ONVIF/SDK/API |
|---|
|
| Video Parameters |
|---|
| Image Format | JPEG |
|---|
| Video Compression Standard | H.264/H.265 |
|---|
|
| AI Functions |
|---|
| AI Recognition | AI Analytics, Human/Vehicle Recognition, Intrusion Detection |
|---|
| AI Alarm | Supports abnormality detection and alarm linkage for network disconnection, IP conflicts, storage errors, unauthorized access, and sensor burnout warnings |
|---|
| Alarm Linkage | Recording / Snapshot / Email / PTZ Linkage |
|---|
|
| System Interfaces |
|---|
| Power Interface | DC 18‑36 V (24 V Typical) |
|---|
| Communication Interface | 1 × RJ45 10/100 Mbps Adaptive Ethernet Port |
|---|
| Storage Interface | Supports MicroSD Card (up to 1 TB) |
|---|
|
| General Specifications |
|---|
| Operating Temperature and Humidity | -20℃~+50℃ |
|---|
| Ingress Protection Rating | IP66 |
|---|
| Power Consumption | ≤18W@25℃ |
|---|
| Dimensions | 112×116×189mm |
|---|
| Weight | Base Mount |
|---|
| Explosion-proof Mark | 2.3kg |
|---|
|
| AI Detection Range |
|---|
| Lens Configuration | 19mm, 25mm |
|---|
| Person (1.8 × 0.5 m) | 0.2km, 0.26km |
|---|
| Vehicle (1.4 × 4.0 m) | 0.6km, 0.8km |
|---|
|
