| Performance Indicators |
|---|
| Detector Type | Uncooled VOx infrared detector |
|---|
| Resolution | 640×512 |
|---|
| Frame Rate | 50 Hz (60 Hz, optional) |
|---|
| Pixel Pitch | 12μm |
|---|
| Spectral Band | 8~14μm |
|---|
| NETD | ≤40mK at 25℃, F#1.0 |
|---|
|
| Image Adjustment |
|---|
| Polarity | Black-hot/White-hot |
|---|
| Palette | Support |
|---|
| Reticle | Display/Blank/Move |
|---|
| Digital Zoom | 1.0~8.0 continuous zoom (step size:0.1) |
|---|
| Image Processing | Scene-based non-uniformity correction, digital filtering noise reduction, and digital detail enhancement, Shutterless |
|---|
| Mirroring | Horizontal/Vertical/Diagonal |
|---|
|
| Power Supply |
|---|
| Power Supply Range (typical) | 3.9~5V DC, 5~18V DC supported by user extension components |
|---|
| Typical Power Consumption at 25°C Without Extension | ≤0.7W |
|---|
| Power Protection | Overvoltage, undervoltage, and reverse connection supported by user extension components |
|---|
|
| Interface |
|---|
| Digital Video | BT.656/DVP/LVCMOS |
|---|
| Analog Video | 1-channel PAL system |
|---|
| Serial Communication Interface | RS232/UART (3.3V) |
|---|
| Extension Components | MIPI/USB/Analog video/BT.656/DVP |
|---|
|
| Physical Characteristics |
|---|
| Dimensions (Without lens and extension components) | 26mm×26mm×19.8mm |
|---|
| Weight (3.2mm, without extension components) | 21g±1g |
|---|
|
| Environment Adaptability |
|---|
| Operating Temperature | -40°C~+80°C |
|---|
| Storage Temperature | -45℃～+85℃ |
|---|
| Humidity | 5 ~ 95%, non-condensing |
|---|
| Vibration | 6.06g, random vibration, all axes |
|---|
| Impact | 1000g@0.3ms, optical axis direction |
|---|
|
