| Performance Indicators |
|---|
| Detector Type | Uncooled VOx infrared detector |
|---|
| Resolution | 384×288 |
|---|
| Detector Frame Rate | 25 Hz |
|---|
| Pixel Pitch | 12μm |
|---|
| Spectral Band | 8~14μm |
|---|
| NETD | ≤50mK at 25°C (≤40mK, optional) |
|---|
|
| Image Adjustment |
|---|
| Brightness/Contrast Adjustment | Manual/Auto |
|---|
| Polarity | Black-hot/White-hot |
|---|
| Palette | Multiple types support |
|---|
| Reticle | Display/Blank/Move |
|---|
| Image Processing | TEC-less temperature control algorithm, digital filtering noise reduction, and digital detail enhancement. |
|---|
| Mirroring | Horizontal/Vertical/Diagonal |
|---|
|
| Power Supply |
|---|
| Power Supply Range (typical) | 3.8～5.2VDC / 1.8V / 3.3V |
|---|
| Typical Power Consumption at 25°C Without Extension | ≤0.25W (Typical, @25°C, Without Extension) |
|---|
|
| Interface |
|---|
| Digital Video | BT.656/BT.1120/LVCMOS |
|---|
| Serial Communication Interface | UART |
|---|
| Extension Components | USB 2.0 / Analog video |
|---|
|
| Temperature Measurement Performance |
|---|
| Measurement Range | For measurement series, -20°C~+550°C (+650°C customizable) |
|---|
| Measurement Accuracy | For measurement series, ±3°C or ±3% of reading (The greater shall prevail) at Ambient temperature of -20°C~+60°C±2°C (optional) |
|---|
| Measurement Tool | Temperature measurement series: Secondary analysis of points, lines, and areas |
|---|
|
| Physical Characteristics |
|---|
| Dimensions (Without lens and extension components) | 18×18mm |
|---|
| Weight (3.2mm, without extension components) | 3.5g |
|---|
| Lens Model | 2.88mm, 5.3mm, 10.4mm, 19mm, expandable to 45mm |
|---|
|
| Environment Adaptability |
|---|
| Operating Temperature | -40°C~+80°C (-20°C~60°C measurement) |
|---|
| Storage Temperature | -45℃～+85℃ |
|---|
| Humidity | 5 ~ 95%, non-condensing |
|---|
| Product Certification | RoHS |
|---|
|
