| Performance Indicators |
|---|
| Detector Type | Uncooled VOx infrared detector
|
|---|
| Resolution | 640×512
|
|---|
| Frame Rate | 50 Hz
|
|---|
| Pixel Pitch | 12μm
|
|---|
| Spectral Band | 8~14μm
|
|---|
| NETD | ≤50mK at 25°C (≤40mK, optional)
|
|---|
|
| Image Adjustment |
|---|
| Brightness/Contrast Adjustment | Manual/Automatic/Linear
|
|---|
| Polarity | Black-hot/White-hot
|
|---|
| Palette | Support
|
|---|
| Reticle | Display/Blank/Move
|
|---|
| Digital Zoom | 1.0~4.0× continuous zoom (step size: 0.1)
|
|---|
| Image Processing | Scene-based non-uniformity correction, digital filtering noise reduction, and digital detail enhancement, Shutterless
|
|---|
| Mirroring | Horizontal/Vertical/Diagonal
|
|---|
|
| Power Supply |
|---|
| Power Supply Range (typical) | 3.5~18V DC supported by user extension components, 4~5.5V DC
|
|---|
| Typical Power Consumption at 25°C Without Extension | ＜0.6W
|
|---|
| Power Protection | Overvoltage, undervoltage, and reverse connection supported by user extension components
|
|---|
|
| Interface |
|---|
| Digital Video | BT.656/BT.1120/14Bit or 8Bit LVCMOS/LVDS
|
|---|
| Analog Video | 1-channel PAL system
|
|---|
| Serial Communication Interface | UART (3.3V)/RS232
|
|---|
| Extension Components | MIPI/USB/Camera Link/Analog video/BT.656/LVDS
|
|---|
|
| Physical Characteristics |
|---|
| Dimensions (Without lens and extension components) | 26mm×26mm×19.2mm
|
|---|
| Weight (3.2mm, without extension components) | 20g±3g
|
|---|
|
| Environment Adaptability |
|---|
| Operating Temperature | -40°C~+80°C
|
|---|
| Storage Temperature | -45℃～+85℃
|
|---|
| Humidity | 5 ~ 95%, non-condensing
|
|---|
| Vibration | 6.06g, random vibration, all axes
|
|---|
| Impact | 80g, 4ms, final peak sawtooth wave, three axes and six directions
|
|---|
|
