| Thermal Imaging |
|---|
| Detector Type | Uncooled infrared detector
|
|---|
| Infrared Resolution | 640×512
|
|---|
| Pixel Size | 12μm
|
|---|
| Super Resolution | 1280×1024
|
|---|
| Spectral Band | 7.5-14μm
|
|---|
| NETD | ＜35mK (25°C,F1.0)
|
|---|
| Frame Rate | 25 Hz
|
|---|
| Lens Focal Length | Standard lens: 17.7mm; super telephoto lens: 60.9mm; telephoto lens: 31.5mm; wide-angle lens: 9.5mm; macro lens (0.2×): 13mm; super macro lens (0.4×): 14.8mm.
|
|---|
| FOV | Standard lens: 25°×20°; super telephoto lens: 7°×5.6°; telephoto lens: 14°×11.2°; wide-angle lens: 45°×36°.
|
|---|
| IFOV | Standard lens: 0.68mrad; super telephoto lens: 0.2mrad; telephoto lens: 0.38mrad; wide-angle lens: 1.26mrad; Macro lens: One pixel corresponds to 60μm; super macro lens: One pixel corresponds to 30μm.
|
|---|
| Focusing Mode | Electric micro focus, manual focusing, one-button center focus, automatic center focus, single-touch automatic focusing, laser-assisted focus
|
|---|
| Measurement Range | -20°C~+150°C, 100°C~650°C; optional: 400°C~+1500°C
|
|---|
| Measurement Accuracy | ±2°C or ±2% of readings, whichever is greater
|
|---|
|
| Imaging Display |
|---|
| Display | 5-inch OLED touch screen, resolution 1280×720
|
|---|
| Visible Light Camera | 13 megapixels
|
|---|
| Digital Zoom | 1× ~ 10×
|
|---|
| Palettes | 19 options
|
|---|
| Image Mode | Infrared, visible light, PIP, dual-spectrum fusion
|
|---|
| Temperature Width Stretch | Support
|
|---|
|
| Image Storage |
|---|
| Storage Medium | Standard 64GB Micro SD, Support SD, SDHC, SDXC,up to 2TB
|
|---|
| Text Notes | Support
|
|---|
| Voice Annotation | Support
|
|---|
|
| Measurement and Analysis |
|---|
| Analysis Functions on the Device | Support up to 20 movable points, lines, frames, circles and polygons, and up to 5 preset modes
|
|---|
| Laser Rangefinding | Support
|
|---|
| Area Measurement | Support
|
|---|
| Hygrothermograph | Support
|
|---|
| Position | Support
|
|---|
| Temperature Difference Analysis | Support
|
|---|
| Trend Analysis | Supports temperature trend recording and analysis.
|
|---|
| Image Freezing | Support
|
|---|
| Analysis Report | PDF format. Support editing and template importing on the PC client.
|
|---|
| Supporting Software | PC (Infrared Analysis Software) & Mobile Device (iOS/Android APP)
|
|---|
|
| Video Functions |
|---|
| Radiation Infrared Video Recording | Support compressed full radiation video recording (.irv), up to 25Hz video recording.
|
|---|
| Non-radiation Infrared or Visible Light Video Recording | Standard MP4 video recording
|
|---|
| Radiation Infrared Video Stream Transmission | TYPE-C/WLAN connection to PC, for real-time transmission of radiation infrared video streams
|
|---|
| Non-radiation Infrared Video Stream Transmission | RTSP H.264
|
|---|
| Video Resolution | 1280×720
|
|---|
|
| System Functions |
|---|
| Intelligent Image Stabilization | Support
|
|---|
| Intelligent Panoramic Stitching | Support panoramic stitching on the PC client, and one-click synthesis.
|
|---|
| Intelligent Routine Inspection | Support. General task package import and editing, standard and automatic naming of images
|
|---|
| Routine Inspection Record Self-inspection | Support
|
|---|
| Dual-Spectrum Video Recording | Simultaneous infrared video and visible light video recording, in MP4 format.
|
|---|
| Communication Protocol | Wi-Fi, Bluetooth, USB, DP, Type-C to HDMI
|
|---|
| Voice Control | Voice assistant, quick command recognition
|
|---|
| Flashlight | Support
|
|---|
|
| Others |
|---|
| Microphone/Speaker | Support
|
|---|
| Battery | 10,000mAh lithium-ion battery, field-replaceable, support fast charging
|
|---|
| Charging Mode | USB Type-C or desktop charger
|
|---|
| Battery Life | Continuous operating time ≥ 6 hours (depending on the actual environment and service conditions)
|
|---|
| Interface | USB3.0 Type-C, SD card, SIM card, Mini HDMI
|
|---|
| Tripod Socket | UNC 1/4-20 interface for tripod
|
|---|
| Operating Temperature | -20°C~+55°C
|
|---|
| Operating Humidity | 10%~95% (non-condensing)
|
|---|
| Storage Temperature | -40°C~+70°C
|
|---|
| Ingress Protection Rating | IP54
|
|---|
| Shock and Vibration | Shock: 25g (IEC 60068-2-27); vibration: 2.5g (IEC60068-2-6)
|
|---|
| Weight and Dimensions | About 1.3kg (with battery), 144×129×307mm
|
|---|
| Authentication | CE/RoHS/CMA, etc.
|
|---|
| Packing List | Thermal camera, standard lens, lithium-ion battery×2, charging stand, charger (with plug for use in multiple countries), charging cable, Bluetooth headset, SD card 64G, Type-C cable, lens hood, mold drawing, data download card, calibration certificate, certificate of qualification, hand strap (with buckle), safety box, lens cap (with screws).
|
|---|
|
