| Performance Indicators |
|---|
| Detector Type | Uncooled VOx infrared detector
|
|---|
| Resolution | 640×512
|
|---|
| Detector Frame Rate | 25 Hz
|
|---|
| Pixel Pitch | 12μm
|
|---|
| Spectral Band | 8~14μm
|
|---|
| NETD | ≤40mK at 25℃,F#1.0
|
|---|
|
| Image Adjustment |
|---|
| Palette | Support (20 types)
|
|---|
| Digital Zoom | 1.0~8.0× continuous zoom (step size: 0.1)
|
|---|
| Image Processing | Non-uniformity correction/Brightness and contrast adjustment/Temporal filtering/Spatial filtering noise reduction/Digital detail enhancement/Style adjustment
|
|---|
| Mirroring | Horizontal/Vertical/Diagonal
|
|---|
|
| Network Function |
|---|
| Network Protocol | TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, IGMP, SMTP, NTP, QoS and other network protocols.
|
|---|
| Platform Access | Support Modbus TCP, MQTT protocols, ONVIF, GB28181, and SDK
|
|---|
| Simultaneous Previewed Videos | Up to 8 channels
|
|---|
| User Management | Up to 20 users, 3 levels: administrator, operator and user
|
|---|
| Browser | Google, Firefox, Edge, etc.
|
|---|
|
| Intelligent Functions |
|---|
| Intelligent Video | Support
|
|---|
| Intelligent Alarm | Support abnormality detection and linkage alarm for network cable disconnection, IP address conflict, memory error, and illegal access
|
|---|
| Intelligent Detection | Supports intelligent analysis of events such as regional intrusion, tripwire intrusions and passenger and vehicle recognition.
|
|---|
| Alarm Linkage | Video taking/Image capture (thermal image capture supported)/Email/Linked PTZ/Alarm output
|
|---|
|
| Lens |
|---|
| Lens Type | Athermalized/Prime electric focus
|
|---|
| Focus Mode | Manual/Automatic
|
|---|
| Electric Focusing | Support
|
|---|
| Electric Zooming | /
|
|---|
|
| Digital |
|---|
| Power Supply Range | 5-24V DC (Recommended voltage of 12V DC)
|
|---|
| Typical Power Consumption at 25°C | ＜1.5w
|
|---|
| Digital Video | LVCMOS/BT.601/BT.1120
|
|---|
| Communication Interface | RS-232/UART
|
|---|
|
| Network Type |
|---|
| Power Supply Range | 12V DC ±10%
|
|---|
| Typical Power Consumption at 25°C | ＜2.4w (Typical, @25°C)
|
|---|
| Communication Interface | One RJ45 10M/100M adaptive Ethernet port, one RS-485, one UART
|
|---|
| Alarm Interface | 1-channel alarm input, 1-channel alarm output
|
|---|
| Audio Interface | 1-channel audio input, 1-channel audio output
|
|---|
|
| Interface |
|---|
| Analog Video | 1-channel PAL system
|
|---|
|
| Environment Adaptability |
|---|
| Operating Temperature | -40℃～+70℃
|
|---|
| Storage Temperature | -45℃～+85℃
|
|---|
| Humidity | 5-95%, non-condensing
|
|---|
| Product Certification | RoHS2.0
|
|---|
|
| PTZ Function |
|---|
| Fire Warning | Supports fire point detection.
|
|---|
|
| Thermal Imaging |
|---|
| Measurement Range | -20℃~﹢150℃, 0℃~﹢650℃
|
|---|
| Measurement Accuracy | ±2°C or 2% (The greater shall prevail)@ambient temperature -20°C ~ +60°C
|
|---|
|
