| Thermal Imaging |
|---|
| Detector Type | Uncooled infrared detector
|
|---|
| Infrared Resolution | 384×288
|
|---|
| Pixel Size | 12μm
|
|---|
| Spectral Band | 7.5-14μm
|
|---|
| NETD | ＜35mK (25°C,F1.0)
|
|---|
| Frame Rate | 30 Hz
|
|---|
| Lens Focal Length | 9.1mm
|
|---|
| FOV | 27°×20°
|
|---|
| IFOV | 1.31mrad
|
|---|
| Focusing Mode | Manual focusing
|
|---|
| Measurement Range | -20°C~+150°C; 100°C~650°C
|
|---|
| Measurement Accuracy | ±2°C or ±2% of readings, whichever is greater
|
|---|
|
| Imaging Display |
|---|
| Display | 3.5-inch touch screen, 640×480 resolution
|
|---|
| Visible Light Camera | 5 megapixels
|
|---|
| Digital Zoom | 1×, 2×, 4×, 8×
|
|---|
| Palettes | 10
|
|---|
| Image Mode | Infrared, visible light, PIP, dual-spectrum fusion
|
|---|
| Temperature Width Stretch | Automatic/Manual
|
|---|
|
| Image Storage |
|---|
| Storage Medium | Standard 32GB MicroSD, up to 512G
|
|---|
| Text Notes | Support
|
|---|
| Voice Annotation | Support
|
|---|
|
| Measurement and Analysis |
|---|
| Analysis Functions on the Device | Custom points/lines/areas; up to 10 points, 10 areas, and 10 lines; Center point/Hot and cold spot tracking and temperature display
|
|---|
| Supporting Software | PC (Infrared Analysis Software) & Mobile Device (iOS/Android APP)
|
|---|
|
| Video Functions |
|---|
| Radiation Infrared Video Recording | Support
|
|---|
| Non-radiation Infrared or Visible Light Video Recording | Support
|
|---|
|
| System Functions |
|---|
| Intelligent Routine Inspection | Support
|
|---|
| Communication Protocol | Wi-Fi, USB
|
|---|
| Video Transmission | Support UVC video transmission
|
|---|
| Laser Pointer | Support
|
|---|
|
| Others |
|---|
| Battery | Rechargeable and detachable lithium-ion battery
|
|---|
| Charging Mode | USB Type-C or desktop charger
|
|---|
| Battery Life | About 6h (about 3h for a single battery)
|
|---|
| Interface | USB Type-C, SD card
|
|---|
| Tripod Socket | UNC 1/4-20 interface for tripod
|
|---|
| Operating Temperature | -10°C~+50°C
|
|---|
| Operating Humidity | 10%~95% (non-condensing)
|
|---|
| Storage Temperature | -20°C~+60°C
|
|---|
| Ingress Protection Rating | IP54
|
|---|
| Shock and Vibration | Shock: 25g (IEC 60068-2-27); vibration: 2.5g (IEC60068-2-6)
|
|---|
| Weight and Dimensions | About 683.5g, 258.4×105.1×102.3mm
|
|---|
| Authentication | CE/RoHS/CMA, etc.
|
|---|
| Packing List | Thermal camera, 5V 3A power adaptor, USB cable, SD card, battery ×2, Quick Start Guide, battery charger, calibration certificate, package list, safety box
|
|---|
|
