| Thermal Module |
|---|
| Detector Type | Uncooled VOx infrared detector
|
|---|
| Spectral Range | 8~14μm
|
|---|
| NETD | ≤40mK(@25°C, F#1.0, 25 Hz)
|
|---|
| Resolution | 1280×1024
|
|---|
| Pixel Pitch | 12μm
|
|---|
| Focal Length | 25~225mm/35~350mm
|
|---|
|
| Optical Module |
|---|
| Sensor | 1/1.8-inch 4 megapixel CMOS image sensor
|
|---|
| Resolution | 2688×1520
|
|---|
| Focal Length | 15~775mm/20~1200mm
|
|---|
|
| GNSS |
|---|
| Satellite Positioning | Satellite location module
|
|---|
|
| PTZ |
|---|
| Pan | 360° continuous，0.01°~120°/s
|
|---|
| Tilt | -90°~+90°，0.01°~60°/s
|
|---|
| Scan mode | Preset point/Patrol inspection group/Patrol inspection scan/Linear scan/Pattern scan
|
|---|
|
| Smart Function |
|---|
| Fire Detection | Support
|
|---|
| Alarm Linkage | Video taking/Image capture/Email/Linked PTZ/Alarm output
|
|---|
| Fire Point Detection | Support
|
|---|
| Intelligent Alarm | Abnormality detection and linkage alarm for network cable disconnection, IP address conflict, full memory, memory error, and illegal access
|
|---|
| Intelligent Detection | Tripwire detection, regional intrusion, and other intelligent video analysis functions
|
|---|
| Intelligent Recognition | Recognition and tracking of people, vehicles, ships, UAVs
|
|---|
|
| System Interface |
|---|
| Power | DC 48V±15%
|
|---|
| Audio | 1-channel audio input, 1-channel audio output
|
|---|
| Alarm | 7-channel input, 2-channel output
|
|---|
| Storage | Micro SD card (up to 1 TB)
|
|---|
| Serial Port | 1-channel RS485 interface
|
|---|
| Network | One RJ45 10 M/100 M adaptive Ethernet port
|
|---|
|
| General |
|---|
| Work Environment | -40℃~+70℃；<90%RH
|
|---|
| Protection | IP66, TVS 6000V, lightning protection, surge protection, and spike protection
|
|---|
| Power Consumption | Max.270W
|
|---|
| Dimenstion(mm) | 805.6×661.5×585.3mm(W×H×L)
|
|---|
| Weight | 80kg
|
|---|
|
